General:
- 80 Plus Rating: GOLD
- ATX Version: ATX 3.0 & ATX 3.1
Protections:
- OCP (Over Current Protection)
- OVP (Over Voltage Protection)
- OPP (Over Power Protection)
- OTP (Over Temperature Protection)
- UVP (Under Voltage Protection)
- SCP (Short Circuit Protection)
- NLO (No Load Operation)
- SIP (Surge and Inrush Protection)
Certifications:
- CE
- CB
- FCC (IC)
- TUV
- cTUVus
- TUV S-Mark
- NOM
- BSMI
- UKCA
- EAC
- CCC
- RCM
Power Factor Correction:
- PFC > 0.99
Input Specifications:
- Voltage: 100-240V
- Current: 12A
- Frequency: 47Hz-63Hz
DC Output Voltages:
- +5V
- +3.3V
- +12V
- -12V
- +5Vsb
Total Output:
- +5V/+3.3V : 22A
- +12V : 70.8A
- -12V : 0.3A
- +5Vsb : 3A
Power Excursion:
- 1997W (up to 235% of the PSU’s rated power for 100μs)
Operating Temperature:
- 50°C
Fan:
- Size: 120mm FDB (Fluid Dynamic Bearing) Fan
- Bearing: FDB (Fluid Dynamic Bearing)
- Speed: 2400 RPM
MTBF:
- 100K hours at full load
Connectors:
- ATX 24 Pin: 1
- EPS 8 Pin: 2
- PCI-E 6+2 Pin: 6
- Molex 4 Pin: 4
- 12VHPWR (12 + 4) Connector (600W): 1
- SATA Connector: 8
