XPG Core Reactor II VE 750W 80+ Gold Fully Modular ATX 3.1
80 Plus Rating:
GOLD
ATX Version:
Intel ATX 12V v3.1
Protections:
OVP / OPP / SCP / OCP / UVP / OTP / NLO / SIP
Certification:
CB / CE / FCC / TUV / cTUVus / BSMI / CCC NOM / FCC IC / UKCA / TUV / TUV S-Mark / cTUVus
PFC:
0.99
Input Voltage:
100-240V
Input Current:
10A
Input Frequency:
47Hz-63Hz
DC Output Voltage:
+5V | +3.3V | +12V | -12V | +5Vsb
Total Output:
+5V/+3.3V :22A, +12V:62.5A, -12V:0.3A, +5Vsb:3A
Power Excursion:
1762W (*up to 235% of the PSU’s rated power for 100μs)
Operating Temperature:
40°C
Fan Size:
120mm FDB Fan
Fan Bearing:
FDB (Fluid Dynamic Bearing)
Fan Speed:
2400 RPM
MTBF:
100K hours at full load
ATX 24 Pin Connector:
1
EPS 8 Pin Connector:
2
PCI-E 6+2 Pin Connector:
3
Molex 4 Pin Connector:
2
12V-2×6 (12+4) Connector (600W):
1
SATA Connector:
6
