SPECIFICATIONS
Prouduct Name
Connect 360
CPU Support
Intel®: LGA 1851/1700/1200/115X/20XX
AMD®: AM5/AM4
Radiator Dimensions
397x120x27mm
Radiator Material
Aluminum
Tube Length
450mm White Sleeved Tube
Pump Dimensions
90x76x67mm
Pump Bearing
Ceramic Bearing
Pump RPM
2700±10% RPM
Pump Noise
≤27dBA
Pump Rated Voltage
12VDC
Pump Rated Current
0.48A
Pump Power Consumption
≤5.76W
Pump Physical Appearance
3.4” LCD Pump Head
TDP
320W
Fan Dimensions
360x120x28mm
Fan Physical Appearance
Addressable RGB Rainbow
Lighting Display
Fan Bearing
Long Life Hydro Bearing
Fan RPM
800-2100±10% RPM
Fan Rated Voltage
12VDC
Fan Rated Current
0.65A
Fan Power Consumption
≤8W
Fan Airflow
80CFM x3
Fan Air Pressure
3.14mm-H2O
Fan Noise
