CPU
- Socket: LGA1851
- Support: Intel Core Ultra Processors
- L3 Cache: Varies with CPU
Chipset
- Model: Intel Z890 Express Chipset
Memory
- Support for DDR5:
- Ranges: 9500(O.C) to 5600MT/s
- DIMM Sockets: 4 x DDR5
- Maximum Capacity: Up to 256 GB (64 GB per DIMM)
- Channel: Dual channel
- Support:
- ECC Un-buffered DIMM (operating in non-ECC mode)
- Non-ECC Un-buffered DIMM
- Extreme Memory Profile (XMP)
- CUDIMM memory module
Onboard Graphics
- Integrated Graphics Processor: Intel® HD Graphics
- Connectors:
- 2 x Intel® Thunderbolt™ 4 (USB4® USB Type-C®)
- 1 x Front HDMI port (1920×1080@30 Hz)
- Triple-Display Support: Yes
Audio
- Codec: Realtek® ALC1220
- Channels: High Definition Audio 2/4/5.1/7.1
- Support: S/PDIF Out
LAN
- Chip: Realtek® 5GbE LAN
- Speed: 5 Gbps/2.5 Gbps/1 Gbps/100 Mbps
Wireless Communication
- Module: Intel® Wi-Fi 7 BE200
- Support:
- 802.11a, b, g, n, ac, ax, be
- Bluetooth 5.4
- 11be 320MHz wireless standard
Expansion Slots
- CPU:
- 1 x PCI Express x16 (PCIe 5.0) (PCIEX16)
- Chipset:
- 1 x PCI Express x16 (PCIe 4.0) (PCIEX4)
- 1 x PCI Express x16 (PCIe 4.0) (PCIEX1)
Storage Interface
- CPU:
- 1 x M.2 (PCIe 5.0 x4/x2 SSD support)
- 1 x M.2 (PCIe 4.0 x4/x2 SSD support)
- Chipset:
- 3 x M.2 (PCIe 4.0 x4/x2 SSD support)
- 1 x M.2 (SATA and PCIe 4.0 x4/x2 SSD support)
- 4 x SATA 6Gb/s connectors
USB
- CPU:
- 2 x Intel® Thunderbolt™ 4 (USB Type-C®)
- Chipset:
- 1 x USB Type-C® (USB 3.2 Gen 2×2)
- 2 x USB 3.2 Gen 2 Type-A (red)
- 6 x USB 3.2 Gen 1
- 8 x USB 2.0/1.1
Internal I/O Connectors
- 1 x 24-pin ATX main power connector
- 2 x 8-pin ATX 12V power connectors
- 1 x CPU fan header
- 1 x CPU fan/water cooling pump header
- 4 x system fan headers
- 2 x system fan/water cooling pump headers
- 3 x addressable RGB Gen2 LED strip headers
- 1 x RGB LED strip header
- 5 x M.2 Socket 3 connectors
- 4 x SATA 6Gb/s connectors
- 1 x front panel header
- 1 x front panel audio header
- 1 x HDMI port
- 1 x USB Type-C® header (USB 3.2 Gen 2×2 support)
- 1 x USB 3.2 Gen 1 header
- 2 x USB 2.0/1.1 headers
- 1 x Trusted Platform Module header
- 1 x Q-Flash Plus button
- 1 x noise detection header
- 1 x power button
- 1 x reset button
- 1 x reset jumper
- 1 x Clear CMOS jumper
Back Panel Connectors
- 4 x USB 2.0/1.1
- 2 x antenna connectors (2T2R)
- 4 x USB 3.2 Gen 1
- 2 x Intel® Thunderbolt™ 4 (USB Type-C®)
- 2 x USB 3.2 Gen 2 Type-A (red)
- 1 x RJ-45
- 1 x optical S/PDIF Out
- 2 x audio jacks
I/O Controller
- Chip: iTE® I/O Controller
H/W Monitoring
- Voltage detection
- Temperature detection
- Fan speed detection
- Water cooling flow rate detection
- Fan fail warning
- Fan speed control
- Noise detection
BIOS
- Flash: 1 x 256 Mbit
- AMI UEFI BIOS
Unique Features
- GIGABYTE Control Center (GCC)
- Q-Flash
- Q-Flash Plus
- Smart Backup
Bundled Software
- Norton® Internet Security (OEM version)
- LAN bandwidth management software
Operating System
- Support: Windows 11 64-bit
Form Factor
- Size: ATX Form Factor; 30.5cm x 24.4cm
