Description
Model NumberBlack: MCA-U000R-KFVK03, White: MCA-U000R-WFVK03
Color(s)Black / Gray, White / Gray
Dimensions (L x W x H)GFX Holder Kit: 249 x 148.1 x 141.8mm (close size), GFX Holder Kit: 305 x 178.1 x 141.8mm (open size), Riser Cable: 165mm (6.19in)
Supported Chassis TypeE-ATX, ATX, Micro ATX (may interfere with component installation on the rear panel. Max. CPU cooler height limited to 70mm.)
Supported Graphics CardsAny length, up to 3 slots wide
Riser Cable ModelRiser Cable PCIe 4.0 x16
CompatibilityPCIe 4.0 and older
CE Certifications NumberBKC210933AC
PCB / Wire UL NumbersE1895721 / E252840
Component MaterialsPCBA, Silver Plated Copper Wire 30 AWG
Insulation MaterialsPE, TPE
Other MaterialsABS, PP, SGCC Steel, Nickel, Gold, Brass
ConnectorsPCIe x16 Male to PCIe x16 90° Female
Rated Working Voltage and CurrentDC 12V / 5A
Operating Temperature-20° to +100° Celsius
Required PCI slotsMinimum 4 PCI slots required for mounting
Weight0.81 kg
Warranty2 years
SeriesOthers
MasteraccessoryCase Accessory
